| Machining Capability | Grinding Diameter Range | Ø4~Ø320 mm | |
| Max Grinding Depth | 200 mm | ||
| Max. WorkpieceSwing Diameter | Ø435 mm | ||
| Swing diameter inside waterproof cover | Ø320 mm | ||
| Controller System | Controller | FANUC | |
| Workhead | Spindle speed | 1000 rpm | |
| X-axis feed rate/ Max. travel | 10 M/min / 750 mm | ||
| Min. display unit | 0.0001 mm | ||
| Workhead rotation angle | -5 ゜~ +30 ゜ | ||
| Worktable | Z-axis feed rate | Z：10 M/min | |
| Z-axis max. travel | Z：320+200 mm | ||
| Z-axis min. display unit | Z：0.0001 mm | ||
| Height of work spindle center from ground | 1100 mm | ||
| Hydraulic system | Tank capacity | 30 L | |
| Cooling system | Cutting fruid tank capacity | 200 L | |
| Servo motor | Hydraulic motor | 0.75 Kw (1Hp) | |
| Cutting fruid motor | 0.37 Kw (1/2Hp) | ||
| X,Y,Z axis servo motor | X：1.6 Kw / Y：1.6 Kw / Z：1.6 Kw | ||
| Grinding wheel motor | Y-axis | 4.0，(5Hp-4P) | |
| Z-axis | 4.0，(5Hp-2P) | ||
| Main spindle head motor | 2.2，(3Hp-4P) | ||
| Others | Automatic lubrication machine | 4 L | |
| Demisions(LxWxH)-Including accessories | 3300x2350x1950mm | ||
| Weight of machine | 5000 kg |
| Standard machine accessories |
| Full Enclosure Guard |
| Internal Circulation Cooling System for Electrical Cabinet |
| Automatic Lubrication System |
| Paper Belt + Magnetic Filter + Water Tank |
| Work Light, Three-Color Warning Light |
| Foundation Screws and Machine Pads |
| Tool Box and Tools |
| Spindle Water Spray |
| Universal Cleaning Spray Gun for Machine |
| Machine, Electrical, and Operating Manuals |
| Two Diamond Pens (Single Point) |
| Transformer + Power Cable |
| Base Plate Packaging |
| Optional accessories: |
| X-Axis Optical Scale (Fagor or HEIDENHAIN) |
| Oil Mist Recovery Machine |
| Oil-Water Separator |
| Power Grinding Mechanism (including metal grinding wheel) |
| Water Tank Temperature Control Device |
